5kWh 10kWh All-in-one Home Solar Battery Storage System With Inverter
Features:
• Vertical industry integration ensures more than >8000 cycles with 80% DoD.
• Integrated inverter design, easy to use, and quick to install. Small size, minimizing installation time and cost Compact and stylish design suitable for your sweet home environment.
• The inverter has a variety of working modes. Whether it is used for the main power supply in the area without electricity or backup power supply in the area with unstable power to deal with sudden power failure, the system can respond flexibly.
• A variety of charging methods can be charged with photovoltaic or commercial power, or both at the same time.
• Can use 4 batteries in parallel at the same time and can provide a maximum of 20kwh for your use.
Contact Us For Bulk Order Price
Description:
Zeconex 5kWh 10kWhAll-in-one Home Solar Battery Storage System With Inverter is the latest version of battery storage system. The newly designed system provides easy connector to save valuable time for installaters. The stacking system provides flexible configurations from 5.12kWh to 10.24 kWh capacity.
Zeconex All-in-one Home Solar Battery Storage System With Inverter is rechargeable home battery system that is installed with solar panel. When the sun rises, solar begins powering the home. When additional power is required for the home, the home can pull it from the utility grid.
Zeconex All-in-one Home Solar Battery Storage System With Inverter is charged by solar during the day, when solar panels are producing more electricity than the home is consuming. Zeconex All-in-one Home Solar Battery Storage System With Inverter then stores that energy until the home needs it, such as when solar is no longer producing at night, or when the utility grid is offline during a power outage.
When the sun comes out the next day, solar recharges Zeconex All-in-one Home Solar Battery Storage System With Inverter so you have a cycle of clean, renewable energy.
Applications:
• Home healthcare
• Home Backup
Tech Specs:
Model | ZECO-AIO48V05-S2 | ZECO-AIO48V10-S2 |
|---|---|---|
Battery Technical Specification | ||
Battery Model | ZECO-AIO48V05-S2 | |
Number of batteries | 1 | 2 |
Battery Energy | 5.12kWh | 10.24kWh |
Battery Capacity | 100AH | |
Weight | 73kg | 118kg |
Dimension L× D× H | Inverter：1x400*580*145mm | Inverter：1x400*580*145mm |
Battery Type | Prismatic LFP | |
Battery Rated Voltage | 51.2V | |
Battery Working Voltage Range | 22.4 ～ 28.8V | |
Maximum Charging Current | 150A | |
Maximum Discharging Current | 150A | |
DOD | 80% | |
Cycling Life Span | ≥8000 (80%DOD, 0.5C, 25°C) | |
PV CHARGE | ||
Solar Charge Type | MPPT | |
Max. Parallel Capacity | 4units（up to 20.48kWh） | |
Rated Output Power | 5000W | |
PV Charging Current Range | 0～80A | |
PV Operating Voltage Range | 120～500V | |
MPPT Voltage Range | 120～450V | |
AC CHARGE | ||
Maximum Charge Power | 2240W | |
AC Charging Current Range | 0～80A | |
Rated Input Voltage | 220/230Vac | |
Input Voltage Range | 90～280Vac | |
AC OUTPUT | ||
Rated Output Power | 3500W | |
Maximum Output Current | 30A | |
Frequency | 50Hz | |
Overload Current | 35A | |
BATTERY INVERTER OUTPUT | ||
Rated Output Power | 3500W | |
Maximum Peak Power | 10,000VA | |
Power Factor | 1 | |
Rated Output Voltage (Vac) | 220Vac（single-phase） | |
Frequency | 50Hz | |
Auto Switch Period | ＜15ms | |
THD | ＜3% | |
GENERAL DATA | ||
Communication | RS485/CAN/WIFI | |
Storage time / temperature | 6 months @25℃;3 months @35℃;1 months @45℃; | |
Charging temperature range | 0～45℃ | |
Discharging temperature range | -10～45℃ | |
Operation Humidity | 5% ～ 85% | |
Nominal Operation Altitude | ＜2000m | |
Cooling Mode | Force-Air Cooling | |
Noise | 60dB(A) | |
Ingress Protection Rating | IP20 | |
Recommended Operation Environment | Indoor | |
Installation Method | Vertical | |
Certification | UN38.3, MSDS, UL1973, IEC62619:2017,EN IEC61000-3-2, EN IEC61000-6-1,RoHS | |
Top All-in-one Home Solar Battery Storage System With Inverter Suppliers In China
Zeconex tops the ranks of All-in-one Home Solar Battery Storage System With Inverter Suppliers in China because:
• Our solar panels battery are made from high-quality batteries and other materials. It is made of cathode materials, battery cell and BMS (battery management system) and processed by Zeconex's self-developed core technologies. The storage battery are sturdy and will last you ages.
• Zeconex High Voltage Energy Storage Battery systems is the latest HESS (home battery storage system). It features high energy and power density, and of course a long lifespan. Its easiness of installation and expansion reflect the real requirements of the end users and strong technical capability of Zeconex. So far, it has served over 50000 families.
• Our solar battery storage for homes are available in a variety of size and capacity from smaller power perfect for small homes and large capactiy to larger house that for solar energy storage.
• You can customize the brand, capacity, finish, and other features of your solar battery storage systems. We can help design solar panel battery storage to your exact requirements.
• Zeconex only supply the best batteries for solar power storage
Leading All-in-one Home Solar Battery Storage System With Inverter Manufacturer
Zeconex is the leading solar panel battery storage manufacturer in the market because:
• Top Quality: Cycle 8000 times, Lifespan up to 10 years, it is very large capacity battery.
• New Prismatic LFP Battery: The solar energy storage system adopts brand-new A-class cells, which can be charged quickly and have good performance.
• Recognized Worldwide: We work with top raw material suppliers to ensure our home and commercial energy storage batteries exceed industry standards. Zeconex Lithium ion solar batteries have been installed in more than 50 countries.
• Our batteries for solar power storage are available for bulk orders at wholesale rates. We provide a one-window operation for all your batteries needs. You can buy energy storage batteries and solar panels at the same time.
• We can customize All-in-one Home Solar Battery Storage System With Inverter to your exact needs. We can add extra features like waterproofing and weatherproofing to make your battries last longer. Your solar battery storage system can be cut to fit your customized solar battery system and be ready to install as soon as they are delivered.
• Our excellent customer service means we’re always ready to help. We can help you choose the right solar energy storage batteries for your project. Our relationship with customers doesn’t end at the successful delivery of home battery storage products. We follow-up with our clients periodically to check if their solar energy storage products are functioning as promised.
