Commercial DC charger (Eco-version) 120-160kW
Features:
Contact Us For Bulk Order Price
Description
120kW-160kW High-Efficiency DC Fast Charger | Zeconex
Boost your EV charging business with the Zeconex Commercial DC Fast Charger—a high-efficiency, dual-output charger designed for fast, reliable, and flexible charging.
Commercial DC charger 160kW is a highly efficient and intelligent charging device with a maximum power of 160kW and a charging efficiency of over 95%. It supports 400VAC±10% input/output power, adapts to 50/60Hz three-phase electricity, and is compatible with CCS2 and GB/T standards. The charger has various safety protection functions, such as over-voltage, under-voltage, overload, and current leakage protection.
Equipped with a 7-inch touch screen, an RFID card, and APP operation, it has an IP55 protection rating for indoor and outdoor installations and an operating temperature range of -30°C to +50°C with a maximum humidity of 95%.
The Commercial DC charger 120kW-160kW also supports Ethernet, 4G, and OCPP 1.6J communication protocols, which makes it easy to monitor and manage remotely. Its output current range is up to 0-200A, and the output voltage range is 150-1000VDC.
In addition, this Commercial DC charger 120kW-160kW product has obtained several international safety certificates, such as EN/IEC 61851-1:2019 and UL2202, to ensure the safety of use.
We also have a similar product to the same model, Commercial DC Charger 60KW-80kW. If you are interested in these products and have a large number of needs, welcome to inquire, large quantity and good price, and quality assurance.
Model | ZECO-1200-DA6 | ZECO-1200-DA7 |
|---|---|---|
Technical Features | ||
Max Power | Up to 120KW | Up to 160KW |
Input/Output power | 400VAC±10%-50/60Hz-3phase(CCS2 and GB/T ) | |
Power factor | 0.98 | |
Efficiency | >95% | |
Measuring accuracy | Level 0.5 | |
Output voltage range | CCS2 CCS1 NACS GB/T: 150~ 1000VDC | |
Output current range | 0-200A | 0-250A |
Communication | ISO15118 / DIN70121(between charger & vehicle) / Ethernet/4G/OCPP 1.6J (TLS1.2 ) | |
User Interface | 7 inch Touch Screen / RFID card and APP | |
Versatility | EN/ IEC 61851-1: 2019 , EN/ IEC 61851-23: 2014 , UL 2202 , Ul2594 | |
Energy Meter | CE certified(optional) | |
RCD | Type A(optional) | |
Security design | Over/ under voltage protection , overload protection , current leakage protection , grounding protection , lightening surge protection | |
DC Plugs | Cable 5M | |
Load balancing | Load balancing meter and CT(optional) | |
Physical Properties | ||
Application place | Indoor / outdoor | |
IP Level | IP55 | |
Installation method | Wall mount , pedestal mount (optional) | |
Sound noise | <75DB in all directions | |
Operating temperature | -30°C to +50°C | |
Humidity | Max .95%(non-regulating) | |
Product Dimensions | 700*240*1700mm | |
Package Dimension | 930*460*1800( L*W* H ) mm | |
Why Choose Zeconex?
Dual-Port Fast Charging – Equipped with two CCS2 / CCS1 / NACS / GB/T connectors, enabling simultaneous charging with a combined output of up to 120-160 kW.
Wide Voltage Range – Constant power output across 150–1000 V, delivering faster charging while minimizing heat generation and energy loss.
Smart & Secure Operation – Supports mobile app control, RFID authentication, plug & play charging, and optional contactless POS payment for flexible user access.
High-Level Protection – IP55-rated enclosure ensures reliable performance in harsh outdoor and commercial environments.
Advanced Connectivity – Compatible with Ethernet and 4G, supports OCPP 1.6 and ISO 15118 Plug & Charge for seamless backend integration.
Certified Safety & Metering – Features Type A RCD protection and a PTB-certified energy meter, ensuring accurate billing and compliance with international standards.
Product Applications
Comprehensive Support
Cloud Platform
Dedicated to enabling the future of e-Mobility with the most open, secure, and robust charging network, our cloud-based EV charging platform makes it easy for operators to manage and customize chargers to their exact needs.
We provide everything required to deliver a complete charging ecosystem, including a management system, mobile app, and seamless interoperability across networks and hardware.
OEM/ODM Service
Our experienced R&D teams in China and abroad specialize in international charging protocols, enabling us to provide reliable OEM and ODM services for clients worldwide.
Comprehensive After-sale Guarantee
If the product is damaged or malfunctions due to manufacturing defects, Zeconex will provide free maintenance or replacement of parts to ensure reliable long-term operation.
