Installation
Provides essential user manuals to ensure the smooth installation and reliable performance of Zeconex charging systems.
Empower Your Project: Guide for Zeconex EV Charging Stations
Thank you for choosing Zeconex products! We are committed to thoughtful engineering and careful planning to ensure you enjoy the safest, most reliable experience, at the best value and quality available. Your trust is the greatest recognition of our efforts.
We provide user manuals that cover key features, performance specifications, external structure, and operating modes. In addition, detailed instructions for installation, operation, and maintenance are included to support every stage of your project.
Product Documentation
Access the user manuals for Zeconex products.
Featuring a friendly interface with a 4.3-inch touchscreen LCD and LED ring, this charger supports fast and safe outdoor charging with CCS2, CCS1, NACS, and GB/T. It offers simple control through a mobile app via Bluetooth or RFID and connects seamlessly to global EV charge management platforms without additional integration, making it suitable for a wide range of applications.
Supports dual charging up to 80 kW with CCS2/CCS1/NACS/GB/T, constant power from 150–1000 V, IP55 protection, app/RFID control, OCPP 1.6, and ISO 15118 Plug & Charge readiness.
This charger supports dual simultaneous charging with CCS2, CCS1, NACS, or GB/T connectors, delivering up to 120 kW with constant power from 150–1000 V. It offers flexible operation via app, RFID, or plug-and-play, features IP55 protection and optional POS payment, and supports Ethernet/4G, OCPP 1.6, and cashless operation. Safety is ensured by a Type A RCD, a PTB-certified energy meter, and Plug & Charge readiness in accordance with ISO 15118/DIN 70121.
Delivering up to 44 kW of fast, efficient charging, this AC charger combines advanced safety protection with smart connectivity through OCPP, WiFi, Ethernet, or optional 4G. A vibrant touchscreen and RFID access ensure an intuitive, user-friendly charging experience.
This innovative charger features dual output sockets, intelligent app control, and a durable, vandal-resistant design. It supports Ethernet, 4G, and Wi-Fi with full OCPP compatibility for smart management and cashless payment. A 55” high-brightness display delivers additional advertising revenue and allows remote content updates.
This smart and easy-to-use wallbox offers RFID start/stop control, intuitive LED indicators, and Bluetooth app operation for seamless home charging. Built with a robust IP54 and IK10-rated structure, it includes Type A + DC 6 mA leakage protection and supports wall-mount or floor-stand installation. Flexible options include Type 1 or Type 2 cables, adjustable 16A/32A output, optional plug-and-play, and a durable 5-meter industrial-grade Type 2 charging cable.
Supports OCPP 1.6+ with CMS integration and offers flexible connectivity via Bluetooth, Wi-Fi, Ethernet, or optional 4G. Designed for simple, intelligent operation, it features an MID-certified meter, Type A+ DC 6 mA protection, and RFID or plug-and-play activation. Built with durable PC940 or galvanized-steel housing and tempered-glass front panel, it’s available in both wall-mounted and floor-stand installations.
Featuring a convenient and stylish design, this charger supports smart WiFi control, app management, and cashless payment. It offers flexible charging capacities of 14kW, 22kW, or 44kW, with optional WiFi, Ethernet, or 4G connectivity. Safety features include over/under-frequency protection and 30mA RCD Type A with DC 6mA or optional Type B protection. It supports floor-stand installation and complies with CE and EN/IEC 61851 standards. Available with dual Type 2 sockets or dual 5m Type 2 charging guns.
